Die Hauptprodukte unseres Unternehmens sind Gattenträger, Walhead, Ballventil, Flussmeter und Globe Ventil .
Ventilkörper
| Ball core form: | full-bore V-shaped |
| Nominal diameter: | DN15-450mm |
| Nominal pressure: | PN16, 40, 64; ANSI150, 300, 600 |
| Connection type: | flange type. Clamp type |
| Valve body material: | WCB, WC6, WC9, LCB, CF8, CF8M, etc. |
| Filling: | PTFE, flexible graphite |
| Valve core form: | metal seal, soft seal |
| Flow characteristics: | equal percentage |
| Internal materials: | 304+PTFE, 316+PTFE, 304, 316, 304L, 316L |
| Model: | Piston actuator |
| Air supply pressure: | 400~700kPa |
| Air source interface: | G1/8″, G1/4″, G3/8″, G1/2″ |
| Ambient temperature: | -30～+70℃ |
| Form of action: | single action, double action |
| Leakage: Metal Seal: | Meets ANSI B16.104 Level IV |
| Non-metallic valve seat: | Meets ANSI B16.104 Level VI |
| Accessories (configured upon request) | Positioner, filter pressure reducing valve, handwheel mechanism, limit switch, solenoid valve, valve position transmitter, pneumatic accelerator, locking valve, etc. |
